Core/cladding alignment / Manual alignment

5s

15s

Automatic heating ( Preheating )

Six motors Auto focus

SM(G.652&G.657), MM ( G.651 ) DS(G.657). NZDS ( G.655 )

0.025dB ( SM ) , 0.01dB ( MM ) 0.04dB ( DS/NZDS )

Real-time control and calibration of fusion ARC

Better than 60DB

Cladding Diameter : 80-150pm
Coating Diameter : 100-1000pm

Coating less than 250pm : 8-16mm
Coating less than 250-1000pm: 16mm

Automatically update,
Update by a key

1 Second

10 languages to switch freely

Standrad 2N

3 in 1 fiber holder, SM, MM, bare fiber, pigtail, rubber-insulated, multi fiber cable

300 for X or Y view, 150 for X or Y view

5 inch TFT color display

Normal / high precision splicing

Fully automatic, Step by step splicing

Synchronize to the phone, the server to cloud storaae unlimited

7800 mA high-capacity lithium battery, charging time 3.5 hours, continuous splicing and heating about 260 times

Input ACIOO-240V 50 / 60HZ, output DC13.5V / 4.8A, the current power mode can be identified, real-time detection of battery power

Temperature -15 — +50 oc, humidity: < 95% RH (no condensation) Working altitude: O — 5000m. Resist max. wind speed: s 15m / s

60mm, 50mm, 40mm& 25mm

Waterproof, dust proof, shock-resistant
